Winters Instruments  |  SKU: BBV3420

Double Block and Bleed Needle Valve, Three Handle

$680.43 USD
Shipping calculated at checkout.
Lead Time: 1-2 Days
NPT Connection
Material

DESCRIPTION & FEATURES:

  • Combines isolating and venting in a single valve, eliminating the need for tubing and fittings
  • Block & bleed design allows pressure to be bled off without disturbing the permanent piping installation, allowing quick and easy removal of replacement instruments
  • The 1/4″ NPT vent plug is located 90° to the left and may be removed and replaced with exhaust piping to direct the fluids to a safe location
  • Available in Hard Seat (10,000 psi)
  • All stems are 316 stainless steel
  • CRN registered
  • 5 year warranty



APPLICATIONS:

  • Ideally suited for severe duty oil and gas installations including refineries and processing plants as well as water treatment plants, power plants and hydraulic applications





Stainless Steel

Stainless Steel

NACE


Body 316 SS 316 SS NACE
Bonnet 316 SS 316 SS NACE
Dustcap
Nylon Nylon
Needle / Needle Tip
316 SS 316 SS NACE
Handle 304 SS 304 SS
Screw 304 SS 304 SS
Fastening Screw
304 SS 304 SS
O-rings FKM FKM
Gland Packing
PTFE PTFE
Dwell Pin 304 SS 304 SS
Vent Plug
316 SS 316 SS NACE
